PCB SMT Stencils Manufacturing
The best quality precision laser cut SMT stencils at low-cost prices. The largest selection of SMT stencils: Laser Cut, Electroformed, Multilayer, and Nano-coated SMT Stencils.
Framed SMT Stencils
Due to its long-lasting engineering, framed SMT stencils are perfect for high-volume use cases. This product is recommended for production runs that need long-term services. Use framed stencils when handling high-volumes of PCBs over an extended time frame.
Framed stencils are also known as glue-in stencils. They contain a permanent stencil frame. A mesh border is used to stretch the stencil foil for high precision. Framed SMT stencils have multiple advantages like:
High print performance: The smooth and rigid hole design leaves precise prints.
Ability to support several applications: Permanent mounting creates high superior integrity levels.
Double-bonding for high-wear uses: Robust engineering resists intense application.
Non-fading fiducial outcomes: The screen-printing process creates durable fiducial layouts.
Unframed SMT Stencils
Since unframed stencils last for an average period, they are suitable for short-term uses. They are recommended for short production runs and
prototype PCB designs. You can also use them in low-volume productions, which are supposed to be done in a short span.
Unframed SMT stencils are made of foils lacking permanent frames. They fit well into reusable frames, and you can detach them easily. Below are the advantages of unframed stencils:
Minimal storage space:
The compact sizes of unframed stencils consumes less space during storage.
Well compatible with screen-printing and hand-printing methods:
Unframed stencils’ versatile designs facilitate machine printing.
Minimal environmental impact:
The use of fewer production materials is good for the environment.
Low-cost prices:
Frameless designs come with a significant price decrease compared to framed stencils.
Super print performance:
High-quality designs ensure super performance throughout the product’s lifespan.
